Hanyang YL800i V- twins engine Heavy motorcycle cruiser Motorbike

Short Description:

The YL800i is a V-twins 800cc cruiser.
YL800i is your first choice if you want to own a V-twins cruiser for your daily driving and fun.


Product Detail

Product Tags

IMG_8931 IMG_8950 IMG_8979 IMG_8992 IMG_9021 IMG_9035 IMG_9036 IMG_9042

Product Description

YL4

In appearance, it can be seen that the YLi800 has the shadow of Harley's Fat bob, especially the front part, but the rear of the YLi800 is not the short tail of the fat bob, the seat does not lower too much, and the tail is much longer.

The dimension of the YLi800 is 2360*830*1070mm, and the wheelbase is 1600mm.

YL5

Lights

The upper and lower layers are arranged with a square headlight with a lens and an LED light strip, which is highly visible.

YL6
YL7

The nighttime of the headlights is very cool, and the lighting at night is also very visible.

handle buttons

The handle buttons are also backlit for smoother operation at night.

YL8

LCD screen

YL9

TFT LCD screen, comprehensive display of motorbike condition information, and can also be connected to a mobile phone via Bluetooth to display the caller number on the meter.

Fuel tank

Drop-shaped fuel tank has a volume of 22L, It has no worries about long-distance travel .

YL10

Decal

Drop-shaped fuel tank has a volume of 22L, It has no worries about long-distance travel .

YL11
YL12

Seats

YL13

Generous high and low seats, the comfort of the front seat is quite good, and the seat height is only 666mm, which is not difficult for most people.

Backrest

The back seat is not equipped with a backrest from the factory. If you buy this motorcycle and need to carry people frequently, it is recommended that you install a backrest. First, the comfort of the rear seat is better, and second is safer.
The 800cc big guy has strong torque, the push-back feeling is very strong when accelerating.

YL14
YL15

LED taillights

YL16

The horizontal "C"-shaped LED taillights run through the tail, and the warning effect is more visible.

Shock absorber

The front inverted shock absorber are adjustable and the rear bilateral spring hydraulic shock absorber are also adjustable.

YL17
YL18

ABS

The front and rear Nissin calipers are equipped with ABS (anti-lock braking system).

YL20
YL19

LOGO

There is a LOGO of Hanyang on the foot pad and on the left cylinder cover.

YL22
YL21

Water tank

YL23

The huge water tank provides good heat dissipation for the engine, which is especially important for large-displacement cruisers.

Motorbike & Tire size

This motorbike is available in both belt and chain, the choice is basic on personal favor.
The tire size is front 140/75-15, and rear 200/55-17.

YL24
YL25

Product Display

YL28
YL30
YL34
YL35
YL36
YL29
YL32
YL33
YL37
YL38

What are the advantages of a motorcycle with two exhaust pipes? The exhaust pipe is also called a muffler. Its main function is to reduce vehicle noise. Secondly, it also has a heat dissipation effect. The design of dual exhaust can reduce exhaust resistance and enhance power. Generally, the exhaust gas of the "V" twins engine comes out from both sides of the cylinder, and it is better to arrange it with double exhaust pipes so that it is inconvenient to combine the exhaust pipes on both sides into a large thick pipe. It is also more beautiful and stylish. When YL800i V twins heavy motorcycle enters a public area, the noise may make people feel relatively loud, so it is recommended to lightly pull the accelerator when entering a public area.

Product Details

Engine
Chassis
Other configuration
Engine
Displacement (ml)  800ml
Cylinders  and number V-twince
Stroke ignition  4 stroke
Valves per cylinder (pcs) 4
Valve structure   Overhead camshaft
Compression ratio  10.3:1
Bore x Stroke (mm)  91 x 61.5mm
Maximum power (kw/rpm)  45Kw/6500rpm
Maximum torque (N m/rpm) 63N.m/5000rpm
Cooling Water
Fuel supply method  EFI
Start   Electric start
Gear shift  International 6 gear
Transmission  Belt drive
Chassis
Length×width×height(mm)  2390*830*1070
Seat height (mm)  720
Ground clearance (mm)  137
Wheelbase (mm) 1600
Total mass (kg)  410
Curb weight (kg)  260
Fuel tank volume (L)  20L
Frame form  Split
Maximum speed (km/h)  180Km/h
Tyre Type High Grip Tyre
Tire  (front) 140/70R17
Tire  (rear)  200/50ZR17
Braking system  Front and rear  disc brakes
Brake Technology  Hydraulic Disc
Suspension system  Front inversion + adjustable hydraulic shock absorption
Other configuration
Instrument  TFT liquid crystal
Lighting  LED
Handle variable diameter
Other configurations Dual-channel ABS anti-lock braking system
Battery  12V14A
