ENGINE
DIMENSIONS & WEIGHT
OTHER CONFIGURATION
ENGINE
Engine |
V-type double cylinder
|
Displacement | 800 |
Cooling type | Water-cooling |
Valves number | 8 |
Bore×Stroke(mm) | 91×61.5 |
Max power(Km/rp/m) | 45/7000 |
Max torque(N.m/rp/m) | 72/5500 |
DIMENSIONS & WEIGHT
Tire (front) |
140/70-17
|
Tire(rear) |
200/50-17
|
Length×width×height(mm) |
2390×870×1300
|
Ground clearance(mm) | 193 |
Wheelbase(mm) | 1600 |
Net weight(kg) | 193 |
Fuel tank volume(L) | 18 |
Maximum speed(km/h) | 160 |
OTHER CONFIGURATION
Drive system | Belt |
Brake system |
Front/rear caliper hydraulic disc type with double channel ABS
|
Suspension system |
Hydraulic disc type
|

Classical appearance, intercourse of yin and yang concept of development, retro design, with classic style.
800cc V shape twin-cylinder water-cooled engine,
Powerful force, inheriting fearless spirit


The thicker seat, soft, more comfortable
320mm floating dual-disc brake disc, matching Nissin's opposite four-piston calipers, auxiliary dual-channel ABS anti-lock system, improve the safety performance of the vehicle when braking


Long tail design, classic v-type retro tail light
Single side double muffler.
Roaring forward, awakening spirit
